ADG733BRUZ

ANALOG DEVICES  ADG733BRUZ  模拟开关, 三通道, SPDT, 3 放大器, 4.5 ohm, 1.8V 至 5.5V, ± 2.5V, TSSOP, 16 引脚

双电源 ±2.5V，Analog Devices

低接通电阻

低失真

高速切换

低泄漏

低功率

得捷:
IC SWITCH TRIPLE SPDT 16TSSOP

立创商城:
ADG733BRUZ

欧时:
双电源 ±2.5V，Analog Devices低接通电阻 低失真 高速切换 低泄漏 低功率### 开关和多路复用器，Analog Devices

e络盟:
模拟开关, 三通道, 3 放大器, SPDT, 4.5 ohm, 1.8V 至 5.5V, ± 2.5V, TSSOP, 16 引脚

艾睿:
Analog Switch Triple SPDT 16-Pin TSSOP Tube

Jameco:
Analog Switch Triple Single Pole Double Throw 5.5 Volt 16-Pin TSSOP

安富利:
The ADG733 is a low voltage, CMOS devices comprising three independently selectable SPDT single pole, double throw switches and four independently selectable SPDT switches respectively.Low power consumption and operating supply range of 1.8 V to 5.5 V and dual ±2.5 V make the ADG733 and ADG734 ideal for battery powered, portable instruments. All channels exhibit break-before-make switching action preventing momentary shorting when switching channels. An EN input on the ADG733 is used to enable or disable the device. When disabled, all channels are switched OFF.These 2-1 multiplexers/SPDT switches are designed on an enhanced submicron process that provides low power dissipation yet gives high switching speed, very low on resistance, high signal bandwidths, and low leakage currents. On resistance is in the region of a few ohms, is closely matched between switches, and is very flat over the full signal range. These parts can operate equally well in either direction and have an input signal range that extends to the supplies.The ADG733 is available in small TSSOP and QSOP packages, while the ADG734 is available in a small TSSOP package.

Chip1Stop:
Analog Switch Triple SPDT 16-Pin TSSOP Tube

Verical:
Analog Switch Triple SPDT 16-Pin TSSOP Tube

Newark:
# ANALOG DEVICES  ADG733BRUZ  Analog Switch, Triple Channel, SPDT, 3 Channels, 2.5 ohm, 1.8V to 5.5V, TSSOP, 16 Pins

Win Source:
IC SWITCH TRIPLE SPDT 16TSSOP
