AD22283-B

单轴，高g ，公司的iMEMS加速度计 Single-Axis, High-g, iMEMS Accelerometers

GENERAL DESCRIPTION

The ADXL193 is a low power, complete single-axis accelerometer with signal conditioned voltage outputs that are all on a single monolithic IC. This product measures acceleration with a full-scale range of ±120 g or ±250 g minimum. It can also measure both dynamic acceleration vibration and static acceleration gravity.

FEATURES

Complete acceleration measurement system on a single monolithic IC

Available in ±120 g or ±250 g output full-scale ranges

Full differential sensor and circuitry for high resistance to EMI/RFI

Environmentally robust packaging

Complete mechanical and electrical self-test on digital command

Output ratiometric to supply

Sensitive axes in the plane of the chip

High linearity 0.2% of full scale

Frequency response down to dc

Low noise

Low power consumption 1.5 mA

Tight sensitivity tolerance and 0 g offset capability

Largest available prefilter clipping headroom

400 Hz, 2-pole Bessel filter

Single-supply operation

Compatible with Sn/Pb and Pb-free solder processes

APPLICATIONS

Vibration monitoring and control

Vehicle collision sensing

Shock detection
