低电压，电阻可编程恒温开关 Low Voltage, Resistor Programmable Thermostatic Switch
This temperature and humidity sensor from Analog Devices will sample ambient conditions. It has an analog output. This device"s minimum operating supply voltage of 2.7 V, while its maximum is 7 V. This part has a temperature range of -50 °C to 150 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery.
得捷:
THERMOSTAT PROG ACT HIGH 8SOIC
贸泽:
Board Mount Temperature Sensors IC 3V TEMP SENSOR
艾睿:
Temp Sensor Analog 8-Pin SOIC N T/R
Chip1Stop:
Temp Sensor Analog 8-Pin SOIC N T/R
Verical:
Temp Sensor Analog 8-Pin SOIC N T/R
供电电流 120 µA
耗散功率 0.23 mW
输出电流Max 10 mA
工作温度Max 150 ℃
工作温度Min -50 ℃
耗散功率Max 0.23 mW
精度 ±2 ℃
电源电压 2.7V ~ 7V
电源电压Max 7 VDC
电源电压Min 2.7 VDC
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
封装 SOIC-8
工作温度 -40℃ ~ 150℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 Non-Compliant
含铅标准 Contains Lead
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
AD22105AR-REEL7 ADI 亚德诺 | 当前型号 | 当前型号 |
AD22105ARZ-REEL7 亚德诺 | 类似代替 | AD22105AR-REEL7和AD22105ARZ-REEL7的区别 |
AD22105AR 亚德诺 | 类似代替 | AD22105AR-REEL7和AD22105AR的区别 |
TC622VOA 微芯 | 功能相似 | AD22105AR-REEL7和TC622VOA的区别 |
