AD633JR-REEL7

低成本模拟乘法器 Low Cost Analog Multiplier

模拟乘法器 四象限 8-SOIC

得捷:
IC MULTIPLIER ANALOG 8-SOIC

艾睿:
Analog Multiplier 4-Bit 8-Pin SOIC N T/R

安富利:
The AD633 is a functionally complete, four-quadrant, analog multiplier. It includes high impedance, differential X and Y inputs, and a high impedance summing input Z. The low impedance output voltage is a nominal 10 V full scale provided by a buried Zener. The AD633 is the first product to offer these features in modestly priced 8-lead PDIP and SOIC packages. The AD633 is laser calibrated to a guaranteed total accuracy of 2% of full scale. Nonlinearity for the Y input is typically less than 0.1% and noise referred to the output is typically less than 100 Ֆ rmsin a 10 Hz to 10 kHz bandwidth. A 1 MHz bandwidth, 20 V/ճ slew rate, and the ability to drive capacitive loads make the AD633 useful in a wide variety of applications where simplicity and cost are key concerns. The versatility of the AD633 is not compromised by its simplicity. The Z input provides access to the output buffer amplifier, enabling the user to sum the outputs of two or more multipliers, increase the multiplier gain, convert the output voltage to a current, and configure a variety of applications. For further information, see the Multiplier Application Guide. The AD633 is available in 8-lead PDIP and SOIC packages. It is specified to operate over the 0Ѓ to 70Ѓ commercial temperature range J Grade or the ?40Ѓ to +85Ѓ industrial temperature range A Grade.

Chip1Stop:
Analog Multiplier 4-Bit 8-Pin SOIC N T/R

罗切斯特:
Analog Multiplier 4-Bit 8-Pin SOIC N T/R
