AMIS41683CANN1RG

容错CAN收发器 Fault Tolerant CAN Transceiver

The new AMIS-41682 and AMIS-41683 are interfaces between the protocol controller and the physical wires of the bus lines in a control area network CAN. AMIS-41683 is identical to the AMIS-41682 but has a true 3.3V digital interface to the CAN controller. The device provides differential transmit capability but will switch in error conditions to a single-wire transmitter and or receiver. Initially it will be used for low speed applications, up to 125kBaud, in passenger cars.Both AMIS-41682 and AMIS-41683 are implemented in I2T100 technology enabling both high-voltage analog circuitry and digital functionality to co-exist on the same chip.These products consolidate the expertise of for in-car multiples transceivers and support together with 0REMX-002-XTP VAN, AMIS-30660 and AMIS-30663 CAN high speed and AMIS-30600 LIN another widely used physical layer.

Features

---

 |

.

Fully compatible with ISO11898-3 standard

.

Very low electromagnetic emission EME

.

Fully integrated receiver filters

.

Permanent monitoring of transmit data input

.

High electromagnetic susceptibility EMS in normal- and low-power modes

.

True 3.3V digital I/O interface to CAN controller

.

In the event of bus failure, automatic switching to single-wire mode

.

The device will automatically reset to differential mode if the bus failure

.

During failure modes there is full wake-up capability

.

Un-powered nodes do not disturb bus lines

.

Bus errors and thermal shutdown activation is flagged on ERRB pin

.

Short circuit proof to battery and ground

.

Thermal protection

.

The bus lines are protected against transients in an automotive environment

.

Support for low power modes

.

Low current sleep and standby mode

.

Power-on flag on the output

.

Two-edge sensitive wake-up input signal via pin WAKEB
