ATMEGA644PA-MU

ATMEGA644PA-MU图片1
ATMEGA644PA-MU图片2
ATMEGA644PA-MU图片3
ATMEGA644PA-MU图片4
ATMEGA644PA-MU图片5
ATMEGA644PA-MU图片6
ATMEGA644PA-MU图片7
ATMEGA644PA-MU图片8
ATMEGA644PA-MU图片9
ATMEGA644PA-MU图片10
ATMEGA644PA-MU图片11
ATMEGA644PA-MU图片12
ATMEGA644PA-MU图片13
ATMEGA644PA-MU概述

ATMEL  ATMEGA644PA-MU  微控制器, 8位, 低功率高性能, ATmega, 20 MHz, 64 KB, 4 KB, 44 引脚, VQFN

The is a high-performance picoPower 8-bit AVR RISC-based Microcontroller combines 64kB ISP flash memory with read-while-write capabilities, 2kB EEPROM, 4kB SRAM, 32 general purpose I/O lines, 32 general purpose working registers, a real time counter, three flexible timers/counters with compare modes and PWM, two USARTs, a byte oriented 2-wire serial interface, a 8-channel 10-bit A/D converter with optional differential input stage with programmable gain, programmable watchdog timer with internal oscillator, SPI serial port, a JTAG IEEE 1149.1 compliant test interface for on-chip debugging and programming and six software selectable power saving modes. The device operates between 1.8 to 5.5V. By executing powerful instructions in a single clock cycle, the device achieves throughputs approaching 1MIPS per MHz, balancing power consumption and processing speed.

.
Advanced RISC architecture
.
Power-on reset and programmable brown-out detection
.
Internal calibrated RC oscillator
.
External and internal interrupt sources
.
Six sleep modes - idle, ADC noise reduction, power-save, power-down, standby and extended standby
.
131 Powerful instructions-most single clock cycle execution
.
32 x 8 General purpose working registers
.
Fully static operation
.
Up to 20MIPS throughput at 20MHz
.
On-chip 2-cycle multiplier
.
QTouch® library support
.
JTAG IEEE std. 1149.1 compliant interface
.
Programmable watchdog timer with separate on-chip oscillator
.
On-chip analog comparator
.
Interrupt and wake-up on pin change
.
Two 8-bit timers/counters with separate prescalers and compare modes
.
One 16-bit timer/counter with separate prescaler, compare mode and capture mode
.
Real-time counter with separate oscillator
.
Six PWM channels
.
Two programmable serial USART
ATMEGA644PA-MU中文资料参数规格
技术参数

频率 20 MHz

电源电压DC 1.80V min

针脚数 44

时钟频率 20.0 MHz

RAM大小 4 KB

位数 8

FLASH内存容量 64 KB

模数转换数ADC 1

输入/输出数 32 Input

工作温度Max 85 ℃

工作温度Min -40 ℃

电源电压 1.8.5.5 V

电源电压Max 5.5 V

电源电压Min 1.8 V

封装参数

安装方式 Surface Mount

引脚数 44

封装 VQFN-44

外形尺寸

长度 7.1 mm

宽度 7.1 mm

高度 0.95 mm

封装 VQFN-44

物理参数

工作温度 -40℃ ~ 85℃ TA

其他

产品生命周期 Unknown

包装方式 Each

制造应用 计量, Metering

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

REACH SVHC标准 No SVHC

REACH SVHC版本 2015/06/15

数据手册

在线购买ATMEGA644PA-MU
型号: ATMEGA644PA-MU
制造商: ATMEL 爱特美尔
描述:ATMEL  ATMEGA644PA-MU  微控制器, 8位, 低功率高性能, ATmega, 20 MHz, 64 KB, 4 KB, 44 引脚, VQFN
