ATXMEGA64A3-AU

ATMEL  ATXMEGA64A3-AU  微控制器, 8位, 低功率高性能, ATxmega, 32 MHz, 64 KB, 4 KB, 64 引脚, TQFP

The is a 8-bit low power high performance AVR Microcontroller features 64kB self-programming flash program memory, 4kB boot code section, 4kB SRAM, 2048B EEPROM, 4-channel DMA controller, 8-channel event system and up to 32 MIPS throughput at 32MHz. The device can be used in a wide range of applications, such as building, board, climate control, hand-held battery applications. By executing powerful instructions in a single clock cycle, the XMEGA A3 achieves throughputs approaching 1 Million Instructions Per Second MIPS per MHz allowing the system designer to optimize power consumption versus processing speed.

.

Non-volatile program and data memories

.

Peripheral features - Four-channel DMA controller with support for external requests

.

Power-on reset POR and programmable brown-out detection

.

Internal and external clock options with PLL

.

Programmable multi-level interrupt controller

.

Sleep modes - Idle, power-down, standby, power-save, extended standby

.

Advanced programming, test and debugging interfaces

.

JTAG IEEE 1149.1 compliant interface for test, debug and programming

.

PDI Program and Debug Interface for programming, test and debugging
