ADF7023-JBCPZ

高性能，低功耗， ISM频段FSK / GFSK / MSK / GMSK收发器IC High Performance, Low Power, ISM Band FSK/GFSK/MSK/GMSK Transceiver IC

GENERAL DESCRIPTION

The ADF7023-J is a very low power, high performance, highly integrated 2FSK/GFSK/MSK/GMSK transceiver designed for operation in the 902 MHz to 958 MHz frequency band, which covers the ARIB Standard T96 band at 950 MHz. Data rates from 1 kbps to 300 kbps are supported.

FEATURES

Ultralow power, high performance transceiver

Frequency bands: 902 MHz to 958 MHz

Data rates supported: 1 kbps to 300 kbps

2.2 V to 3.6 V power supply

Single-ended and differential power amplifiers PAs

Low IF receiver with programmable IF bandwidths 100 kHz, 150 kHz, 200 kHz, 300 kHz

Receiver sensitivity BER

  −116 dBm at 1.0 kbps, 2FSK, GFSK

  −107.5 dBm at 38.4 kbps, 2FSK, GFSK

  −106.5 dBm at 50 kbps, 2FSK, GFSK

  −105 dBm at 100 kbps, 2FSK, GFSK

  −104 dBm at 150 kbps, GFSK, GMSK

  −103 dBm at 200 kbps, GFSK, GMSK

  −100.5 dBm at 300 kbps, GFSK, GMSK
