LF至2.5 GHz TruPwr ？探测器 LF to 2.5 GHz TruPwr? Detector
GENERAL DESCRIPTION
The AD8361 is a mean-respondingpower detectorfor use in highfrequencyreceiver and transmitter signal chains,upto 2.5 GHz.Itis veryeasy toapply.Itrequires a single supplyonly between 2.7 V and 5.5 V,a power supplydecouplingcapacitor, and an input couplingcapacitor in most applications.
FEATURES
Calibrated rms response
Excellent temperature stability
Up to 30 dB input range at2.5 GHz
700 mVrms, 10dBm, re 50Ω maximum input
±0.25 dB linearresponse up to 2.5 GHz
Single-supply operation: 2.7 V to 5.5 V
Low power: 3.3 mW at 3 Vsupply
Rapid power-down to less than 1 µA
频率 100MHz ~ 2.5GHz
电源电压DC 5.50V max
供电电流 1.1 mA
耗散功率 200 mW
热阻 200 ℃/W
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 200 mW
精度 ±0.25 dB
电源电压 2.7V ~ 5.5V
安装方式 Surface Mount
引脚数 8
封装 MSOP-8
长度 3.00 mm
宽度 3.00 mm
封装 MSOP-8
厚度 1.10 mm
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Radar, Aerospace and Defense
RoHS标准 RoHS Compliant
含铅标准 Contains Lead
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
AD8361ARMZ-REEL ADI 亚德诺 | 当前型号 | 当前型号 |
AD8361ARMZ 亚德诺 | 完全替代 | AD8361ARMZ-REEL和AD8361ARMZ的区别 |
AD8361ARM-REEL7 亚德诺 | 完全替代 | AD8361ARMZ-REEL和AD8361ARM-REEL7的区别 |
AD8361ARMZ-REEL7 亚德诺 | 完全替代 | AD8361ARMZ-REEL和AD8361ARMZ-REEL7的区别 |
