ADUC831BCPZ

51系列 16MHz 闪存：62K@x8bit

* ANALOG I/O * 8-Channel, 247 kSPS 12-Bit ADC * DC Performance: 1 LSB INL * AC Performance: 71 dB SNR * DMA Controller for High Speed ADC-to-RAM Capture * 2 12-Bit Monotonic Voltage Output DACs * Dual Output PWM/- DACs * On-Chip Temperature Sensor Function 3 C * On-Chip Voltage Reference * Memory * 62 kBytes On-Chip Flash/EE Program Memory * 4 kBytes On-Chip Flash/EE Data Memory * Flash/EE, 100 Yr Retention, 100 kCycles Endurance * 2304 Bytes On-Chip Data RAM * 8051 Based Core * 8051 Compatible Instruction Set 16 MHz Max * 12 Interrupt Sources, 2 Priority Levels * Dual Data Pointer * Extended 11-Bit Stack Pointer * On-Chip Peripherals * Time Interval Counter TIC * UART, I2C®, and SPI® Serial I/O * Watchdog Timer WDT, Power Supply Monitor PSM * Power * Specified for 3 V and 5 V Operation * Normal, Idle, and Power-Down Modes * Power-Down: 20 A @ 3 V
