ADF4360-5BCPRL

集成的合成器和VCO Integrated Synthesizer and VCO

GENERAL DESCRIPTION

The ADF4360-5 is a fully integrated integer-N synthesizer and voltage-controlled oscillator VCO.The ADF4360-5 is designed for a center frequency of 1300 MHz. Inaddition, a divide-by-2 option is available, whereby the user gets an RF output of between 600 MHz and 700 MHz.

FEATURES

Output frequency range: 1200 MHz to 1400 MHz

Divide-by-2 output

3.0 V to 3.6 V power supply

1.8 V logic compatibility

Integer-N synthesizer

Programmable dual-modulus prescaler 8/9, 16/17, 32/33

Programmable output power level

3-wire serial interface

Analogand digital lock detect

Hardware and software power-down mode

APPLICATIONS

Wireless handsets DECT, GSM,PCS, DCS, WCDMA

Test equipment

Wireless LANs

CATVequipment
