压敏电阻
压敏
得捷:
VARISTOR 8V 25A 0402
立创商城:
AVR-M1005C080MTAAB
贸泽:
Varistors 0402 8V 25A 650pF
艾睿:
Provide proper variable resistance to your circuit by using this AVR-M1005C080MTAAB MOV from TDK. This device&s;s clamping current is 1 A and clamping voltage is 14 V. Its maximum surge current is 25 A. This voltage dependent resistor has an operating temperature of -40 to 125 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. Mount your voltage dependent resistor on a printed circuit board using surface mount technology to produce the most effective results. Its capacitance value is 650pF. The maximum DC voltage rating is 5.5 VDC. Its tolerance voltage is 20%. This device utilizes multilayer technology. This varistor has a voltage of 8 V. This product is 1 mm long, 0.5 mm tall and 0.5 mm deep.
安富利:
Var MLV 5.5VDC 25A 8V 0402 SMD T/R
Chip1Stop:
Var MLV 5.5VDC 25A 8V 0402 SMD Automotive T/R
Verical:
Var MLV 5.5VDC 25A 8V 0402 SMD Automotive T/R
Win Source:
VARISTOR 8V 25A 0402
Electro Sonic:
Var MLV 5.5VDC 25A 8V 0402 SMD Automotive T/R
额定电压DC 5.5 V
额定电压AC 8.00 V
电容 650 pF
电路数 1
钳位电压 14 V
工作温度Max 125 ℃
工作温度Min -40 ℃
额定电压DC Max 5.5 V
安装方式 Surface Mount
封装公制 1005
封装 0402
长度 1 mm
宽度 0.5 mm
高度 0.5 mm
封装公制 1005
封装 0402
材质 Zinc Oxide
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 for Consumer / Industrial, Switch
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
AVR-M1005C080MTAAB TDK 东电化 | 当前型号 | 当前型号 |
AVR-M1005C080MBAAB 东电化 | 完全替代 | AVR-M1005C080MTAAB和AVR-M1005C080MBAAB的区别 |
AVR-M1005C080MTADB 东电化 | 类似代替 | AVR-M1005C080MTAAB和AVR-M1005C080MTADB的区别 |
