AVR-M2012C220KT6AB

AVR-M2012C220KT6AB 0805-22V

压敏

得捷:
VARISTOR 22V 100A 0805

立创商城:
22V 800pF 100A

贸泽:
压敏电阻 0805 22V 100A 800pF AEC-Q200

艾睿:
Provide proper variable resistance to your circuit by using this AVR-M2012C220KT6AB MOV from TDK. This device&s;s clamping current is 5 A and clamping voltage is 38 V. Its maximum surge current is 100 A. This voltage dependent resistor has an operating temperature of -40 to 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. Mount your voltage dependent resistor on a printed circuit board using surface mount technology to produce the most effective results. Its tolerance voltage is 10%. This varistor has a voltage of 22 V. Its capacitance value is 800pF. This product is 2 mm long, 1 mm tall and 1.25 mm deep. The maximum DC voltage rating is 16 VDC. This device is made with multilayer technology.

安富利:
Var MLV 16VDC 100A 22V 0805 SMD T/R

Chip1Stop:
Automotive Grade, Multilayer Chip Varistor, 22V, 800pF, 16VDC, 0805

Verical:
Var MLV 16VDC 100A 22V 0805 SMD Automotive T/R

儒卓力:
**VC 0805 DC=16V CL=38V 0,3J 100A **

MASTER:
Var MLV 16VDC 100A 22V 0805 SMD Automotive T/R

Win Source:
VARISTOR 22V 100A 0805

Electro Sonic:
Var MLV 16VDC 100A 22V 0805 SMD Automotive T/R
