OMRON ELECTRONIC COMPONENTS A6S4104H DIP / SIP开关, SPST, SMD, 4 电路, DIP非密封, 24 VDC
The is a single-pole single-throw SMD DIP Switch with slide actuator style DIP unsealed type. Designed to enable replacement of previous A6S model, featuring the same dimensions and improved solder heat resistance. Gold-plated twin contacts and a slide-type, self-cleaning mechanism ensure high reliability.
- .
- 200mR Maximum contact resistance
- .
- 100MR at 250VDC Minimum insulation resistance
- .
- 10µA at 3.5VDC Minimum permissible load
触点电镀 Gold
额定电压DC 24 V
接触器类型 Standard
方向 Vertical
触点类型 SPST
电路数 4
针脚数 4
额定电流Max 0.025A @24VDC
工作温度Max 70 ℃
工作温度Min -20 ℃
额定电压DC Max 24 V
接触电阻Max 200 mΩ
安装方式 Surface Mount
长度 11.1 mm
宽度 9.8 mm
高度 4.4 mm
工作温度 -20℃ ~ 70℃
包装方式 Tube
制造应用 Industrial, 工业
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2014/06/16
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
A6S4104H Omron 欧姆龙 | 当前型号 | 当前型号 |
1-1825059-3 Alcoswitch | 类似代替 | A6S4104H和1-1825059-3的区别 |
SDA04H0SBR C&K Components | 功能相似 | A6S4104H和SDA04H0SBR的区别 |
SDA04H1SBD C&K Components | 功能相似 | A6S4104H和SDA04H1SBD的区别 |
