开关
is manufactured by Elect and is categorized in the DIP Switches category. A6TN-8101 is described as SWITCH SLIDE DIP SPST 25MA 24V. Perfect Parts is a supplier of Switches and other Electromechanicals.
立创商城:
开关
得捷:
SWITCH SLIDE DIP SPST 25MA 24V
贸泽:
DIP Switches / SIP Switches Slide Type DIP Wht 8Pin, Flat Actuator
艾睿:
Does your printed circuit board need some type of electronic flow control? The A6TN-8101 dual in-line package switch, developed by Omron, is the component you need. This device has a maximum current rating of 0.025 A @ 24VDC. It has a SPST configuration. This DIP switch has an operating temperature range of -30 °C to 85 °C. The A6TN-8101 DIP switch has a PC pin termination style. The maximum DC voltage rating is 24 VDC. This product&s;s terminal pitch is 2.54 mm. This product is 22.3 mm long, 4.8 mm tall and 7.85 mm deep.
安富利:
Switch DIP OFF ON SPST 8 Flat Slide 0.025A 24VDC PC Pins 2.54mm Thru-Hole Stick
Chip1Stop:
Switch DIP OFF ON SPST 8 Flat Slide 0.025A 24VDC PC Pins 2.54mm Thru-Hole Stick
Newark:
# OMRON ELECTRONIC COMPONENTS A6TN-8101 Dip Switch
MASTER:
Switch DIP OFF ON SPST 8 Flat Slide 0.025A 24VDC PC Pins 2.54mm Thru-Hole Stick
Electro Sonic:
Switch DIP OFF ON SPST 8 Flat Slide 0.025A 24VDC PC Pins 2.54mm Thru-Hole Stick
额定电压DC 24 V
额定电流 25 mA
触点类型 SPST
针脚数 8
额定电流Max 0.025A @24VDC
工作温度Max 85 ℃
工作温度Min -30 ℃
额定电压 24 VDC
额定电压DC Max 24 V
接触电阻Max 200 mΩ
安装方式 Through Hole
封装 DIP
长度 22.3 mm
宽度 7.85 mm
高度 4.8 mm
封装 DIP
工作温度 -30℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
