LDO(低压降)线性电压调节器,3.xV 输出,Analog Devices### LDO(低压降)线性电压调节器 - Analog Devices低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
LDO(低压降)线性稳压器,3.xV 输出,Analog Devices
Analog Devices 低压降(LDO)线性调节器提供快速瞬态响应、极佳的线路和负载调节,并且具有宽输入电压范围。
### LDO(低压降)线性电压调节器 - Analog Devices
低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
得捷:
IC REG LINEAR 3.3V 50MA SOT23-6
立创商城:
ADP3300ARTZ-3.3RL7
欧时:
LDO(低压降)线性稳压器,3.xV 输出,Analog DevicesAnalog Devices 低压降(LDO)线性调节器提供快速瞬态响应、极佳的线路和负载调节,并且具有宽输入电压范围。### LDO(低压降)线性电压调节器 - Analog Devices低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
艾睿:
Having trouble maintaining a steady voltage? This LDO ADP3300ARTZ-3.3RL7 linear regulator from Analog Devices will give you control over the voltage levels of your circuit. It has an overall accuracy of ±0.8 %. Its typical dropout voltage at current is 0.08@50mA|0.025@10mA|0.004@1mA V. This voltage regulation device&s;s single output can produce a current up to 0.05Min A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 3 V that does not exceed 12 V. With a fixed output that has a voltage of 3.3 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 0.06mV/mATyp and line regulation of 0.02mV/VTyp. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This voltage regulation device has an operating temperature range of -40 °C to 85 °C. Its polarity is positive. The maximum dropout voltage is 0.03@1mA|0.07@10mA|0.17@50mA V.
Chip1Stop:
LDO Regulator Pos 3.3V 0.05A 6-Pin SOT-23 T/R
Verical:
LDO Regulator Pos 3.3V 0.05A 6-Pin SOT-23 T/R
Newark:
# ANALOG DEVICES ADP3300ARTZ-3.3RL7 Fixed LDO Voltage Regulator, 3V to 12V, 80mV Dropout, 3.3Vout, 50mAout, SOT-23-6
DeviceMart:
IC REG LDO 3.3V 50MA SOT23-6
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3.3V 50mA SOT-23-6
电源电压DC 16.0V max
输出接口数 1
输入电压DC 12.0V max
输出电压 3.3 V
输出电流 50 mA
供电电流 300 µA
针脚数 6
跌落电压 80 mV
输入电压Max 12 V
输入电压Min 3 V
输出电压Min 3.3 V
输出电流Max 100 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
精度 ±1.4 %
电源电压Min 3 V
输入电压 ≤12 V
安装方式 Surface Mount
引脚数 6
封装 SOT-23-6
长度 2.9 mm
宽度 1.6 mm
高度 1.15 mm
封装 SOT-23-6
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 便携式器材, 电源管理, Consumer Electronics, Computers & Computer Peripherals, Power Management, 消费电子产品, Portable Devices, 计算机和计算机周边
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
军工级 No
REACH SVHC版本 2016/06/20
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ADP3300ARTZ-3.3RL7 ADI 亚德诺 | 当前型号 | 当前型号 |
ADP3300ART-3.3-RL7 亚德诺 | 完全替代 | ADP3300ARTZ-3.3RL7和ADP3300ART-3.3-RL7的区别 |
ADP3300ART-5-REEL7 亚德诺 | 完全替代 | ADP3300ARTZ-3.3RL7和ADP3300ART-5-REEL7的区别 |
ADP3300ART-3-REEL7 亚德诺 | 完全替代 | ADP3300ARTZ-3.3RL7和ADP3300ART-3-REEL7的区别 |
