ANALOG DEVICES ADM811-3TARTZ-RL7 监控器电路, 手动复位, 低电平有效复位, 3.15V-3.6V输入, SOT-143-4
监控器 推挽式/图腾柱 1 通道 SOT-143-4
欧时:
Volt. Supervisor 3.08V Low Reset SOT143
得捷:
IC SUPERVISOR 1 CHANNEL SOT143-4
立创商城:
ADM811-3TARTZ-RL7
贸泽:
监控电路 5V CMOS MPU IC Logic Low Reset Bar Output
e络盟:
监控器电路, 手动复位, 低电平有效复位, 3.15V-3.6V输入, SOT-143-4
艾睿:
Using the ADM811-3TARTZ-RL7 microprocessor supervisory circuit from Analog Devices will make sure your circuit is protected from any emergencies. This device has a maximum power dissipation of 200 mW. Its maximum power dissipation is 200 mW. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. It has a typical reset threshold voltage of 3.08 V, with a minimum of 3.03 V and a maximum of 3.14 V. This part has a minimum operating temperature of -40 °C and a maximum of 85 °C. This device has a minimum operating supply voltage of 1 V and a maximum of 5.5 V.
安富利:
Processor Supervisor 3.08V 2.5V/3V/3.3V/5V 4-Pin3+Tab SOT-143 T/R
Chip1Stop:
Processor Supervisor 3.08V 2.5V/3V/3.3V/5V Automotive 4-Pin3+Tab SOT-143 T/R
Verical:
Processor Supervisor 3.08V 1 Active Low/Push-Pull Automotive 4-Pin SOT-143 T/R
Newark:
# ANALOG DEVICES ADM811-3TARTZ-RL7 Supervisor Circuit, 3.15V-3.6V supply, 3.08V Threshold, Active-Low Reset, SOT-143-4
罗切斯特:
Processor Supervisor 3.08V 2.5V/3V/3.3V/5V Automotive 4-Pin3+Tab SOT-143 T/R
Win Source:
IC SUPERVISOR RESET 3.08V SOT143
电源电压DC 5.50V max
供电电流 0.01 mA
针脚数 4
耗散功率 200 mW
阈值电压 3.08 V
复位电压Min 3.03 V
复位电压Max 3.14 V
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 200 mW
电源电压Max 3.6 V
电源电压Min 3.15 V
安装方式 Surface Mount
引脚数 4
封装 TO-253-4
长度 2.9 mm
宽度 1.3 mm
高度 0.9 mm
封装 TO-253-4
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Power Management, 便携式器材, 车用, 传感与仪器, Automation & Process Control, Sensing & Instrumentation, Automotive, 自动化与过程控制, Safety, Portable Devices, 计算机和计算机周边, Computers & Computer Peripherals, 电源管理, 安全
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
军工级 No
REACH SVHC版本 2016/06/20
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ADM811-3TARTZ-RL7 ADI 亚德诺 | 当前型号 | 当前型号 |
ADM811-3TART-REEL 亚德诺 | 完全替代 | ADM811-3TARTZ-RL7和ADM811-3TART-REEL的区别 |
ADM811-3TART-REEL7 亚德诺 | 类似代替 | ADM811-3TARTZ-RL7和ADM811-3TART-REEL7的区别 |
ADM811-3TARTZ-RL 亚德诺 | 类似代替 | ADM811-3TARTZ-RL7和ADM811-3TARTZ-RL的区别 |
