ANALOG DEVICES AD5641ACPZ-REEL7 芯片, 数模转换器, 14位, LFCSP-6
14 位 1 6-LFCSP-WD(2x3)
得捷:
IC DAC 14BIT V-OUT 6LFCSP
艾睿:
DAC 1-CH Resistor-String 14-bit 6-Pin LFCSP EP T/R
安富利:
The AD5641, a member of the nanoDAC® family, is a single, 14-bit, buffered, voltage-out DAC that operates from a single 2.7 V to 5.5 V supply, typically consuming 75 µA at 5 V. The part comes in tiny LFCSP and SC70 packages. Its on-chip precision output amplifier allows rail-to-rail output swing to be achieved. The AD5641 uses a versatile 3-wire serial interface that operates at clock rates up to 30 MHz and is compatible with SPI®, QSPI™, MICROWIRE™, and DSP interface standards. The reference for AD5641 is derived from the power supply inputs and, therefore, gives the widest dynamic output range. The part incorporates a power-on reset circuit, which ensures that the DAC output powers up to 0 V and remains there until a valid write to the device takes place.The AD5641 contains a power-down feature that reduces current consumption typically to 0.2 µA at 3 V, and provides software-selectable output loads while in power-down mode. The part is put into power-down mode over the serial interface. The low power consumption of the part in normal operation makes it ideally suited to portable battery-operated equipment. The combination of small package and low power makes this nanoDAC device ideal for level-setting requirements such as generating bias or control voltages in space-constrained and power-sensitive applications.
Chip1Stop:
DAC 1-CH Resistor-String 14-bit 6-Pin LFCSP EP T/R
罗切斯特:
DAC 1-CH Resistor-String 14-bit 6-Pin LFCSP EP T/R
供电电流 75.0 µA
针脚数 6
位数 14
耗散功率 5.50 mW
分辨率Bits 14.0
工作温度Max 125 ℃
工作温度Min -40 ℃
数模转换数DAC 1
电源电压 2.7V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2.7 V
安装方式 Surface Mount
引脚数 6
封装 LFCSP-6
高度 0.75 mm
封装 LFCSP-6
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Contains Lead
军工级 No
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
AD5641ACPZ-REEL7 ADI 亚德诺 | 当前型号 | 当前型号 |
