ADM1033ARQZ-RL7

温度监控和风扇转速（ RPM ）控制器 Thermal Monitor and Fan Speed RPM Controller

The ADM1033 is a one channel remote- and local-temperature sensor and fan controller. The remote channel monitors the temperature of the remote thermal diode, which may be discrete 2N3904/6s or may be located on a microprocessor die. The device also monitors its own ambient temperature.

Features

---

 |

.

1 Local and 1 Remote Temperature Channels

.

±1.5°C Accuracy on Local and Remote Channels

.

Automatic Series Resistance Cancellation on Remote Temperature Channels, > 100 Ω

.

Fast up to 64 measurements a second

.

SMBus 2.0, 1.1 and 1.0 Compliant

.

SMBus Address Input / Location Input to UDID

.

Programmable Over / Under Temperature Limits

.

Programmable Fault Queue

.

SMBus / ALERT Output

.

Failsafe Over-temperature Comparator Output

.

RPM Fan Speed Control

.

Lookup Table for Temperature to Fan Speed Control
