环境光传感器
Optical Sensor Ambient 560nm Current 0805 2012 Metric
得捷:
SENSOR OPT 560NM AMBIENT 0805
贸泽:
环境光传感器
艾睿:
Light to Current Ambient Light Sensor AnalogCurrent 2-Pin Chip
安富利:
Cadmium Free Sensor 2-Pin Chip T/R
波长 560 nm
峰值波长 560 nm
耗散功率 6 mW
上升时间 1200000 ns
下降时间 1200000 ns
工作温度Max 85 ℃
工作温度Min -30 ℃
耗散功率Max 6 mW
电源电压 1.5V ~ 5.5V
安装方式 Surface Mount
引脚数 2
封装公制 2012
封装 0805
长度 2 mm
宽度 1.25 mm
高度 0.55 mm
封装公制 2012
封装 0805
工作温度 -30℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
