3.3 V , 【 15千伏ESD保护,半双工和全双工, RS - 485 / RS -422收发器 3.3 V, 【15 kV ESD-Protected, Half- and Full-Duplex, RS-485/RS-422 Transceivers
Product Details
The ADM3070E–ADM3078E are 3.3V, low power data transceivers with ±15kV ESD protection suitable for full and half duplex communication on multipoint bus transmission lines. They are designed for balanced data transmission and comply with TIA/EIA standards RS-485 and RS-422. The devices have a 1/8 unit load receiver input impedance which allows up to 256 transceivers on a bus. Since only one driver should be enabled at any time, the output of a disabled or powered down driver is three-stated to avoid overloading the bus.
The receiver inputs have a true failsafe feature which eliminates the need for external bias resistors and ensures a logic high output level when the inputs are open or shorted. This guarantees that the receiver outputs are in a known state before communication begins and when communication ceases.
The ADM307xE are 3.3 V, low power data transceivers with ±15 kV ESD protection suitable for full- and half-duplex communication on multipoint bus transmission lines. They are designed for balanced data transmission, and they comply with TIA/EIA standards: RS-485 and RS-422.
The devices have a ⅛ unit load receiver input impedance, which allows up to 256 transceivers on a bus. Because only one driver should be enabled at any time, the output of a disabled or powered-down driver is tristated to avoid overloading the bus.
The receiver inputs have a true fail-safe feature, which eliminates the need for external bias resistors and ensures a logic high output level when the inputs are open or shorted. This guarantees that the receiver outputs are in a known state before communication begins and when communication ceases.
**Applications**
### Features and Benefits
ADM3070E/ADM3071E/ADM3072E: 250 kbps
电源电压DC 65.0V max
额定电流 120 µA
输出接口数 1
输入电压DC 2.00V ~ 18.0V
输出电压 2 V
输出电流 250 mA
供电电流 1.5 mA
电路数 2, 1, 4
通道数 1
时钟频率 50.0MHz max
位数 8
耗散功率 80.0 mW
数据速率 250 kbps
电阻 10.0 kΩ
阻值偏差 ±20 %
采样率 1.70 MHz
共模抑制比 132 dB
静态电流 3.00 µA
阈值电压 4.65 V
分辨率Bits 10.0
输入电容 2.00 pF
带宽 5.00 MHz
转换速率 5.00 V/μs
增益频宽积 1.00 MHz
输入阻抗 1.00 TΩ
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 3V ~ 3.6V
输入电压 3.3 V
安装方式 Surface Mount
引脚数 8
封装公制 SOIC
封装 SOIC-8
长度 5 mm
宽度 4 mm
高度 1.5 mm
封装公制 SOIC
封装 SOIC-8
工作温度 -40℃ ~ 85℃
温度系数 ±25.0 ppm/℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
军工级 No
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ADM3072EARZ-REEL7 ADI 亚德诺 | 当前型号 | 当前型号 |
ADM3072EARZ 亚德诺 | 类似代替 | ADM3072EARZ-REEL7和ADM3072EARZ的区别 |
ST3485EBDR 意法半导体 | 功能相似 | ADM3072EARZ-REEL7和ST3485EBDR的区别 |
ISL83072EIBZA 英特矽尔 | 功能相似 | ADM3072EARZ-REEL7和ISL83072EIBZA的区别 |
