双通道隔离器,集成DC- DC转换器 Dual-Channel Isolators with Integrated DC-to-DC Converters
Product Details
The ADuM6210/ADuM6211/ADuM6212 are dual-channel digital isolators with _iso_Power®, an integrated, isolated DC/DC converter. Based on the Analog Devices, Inc., _i_Coupler® technology, the DC/DC converter provides regulated, isolated power, adjustable between 3.15 V and 5.25 V. Input supply voltages can range from slightly below the required output to significantly higher.
This eliminates the need for a separate, isolated DC/DC converter in low power, isolated designs. The _i_Coupler chip-scale transformer technology is used for isolated logic signals and for the magnetic components of the DC/DC converter. The result is a small form factor, total isolation solution.
The ADuM6210/ADuM6211/ADuM6212 isolators provide two isolated digital data channels and power in a variety of directional configurations and data rates see the Ordering Guide for more information.
_iso_Power uses high frequency switching elements to transfer power through its transformer. Special care must be taken during printed circuit board PCB layout to meet emissions standards. See the AN-0971 Application Note for board layout recommendations.
**Applications**
### Features and Benefits
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ADUM6211ARSZ-RL7 ADI 亚德诺 | 当前型号 | 当前型号 |
ADUM6211ARSZ 亚德诺 | 完全替代 | ADUM6211ARSZ-RL7和ADUM6211ARSZ的区别 |
