AD5247BKSZ10-2RL7

ANALOG DEVICES  AD5247BKSZ10-2RL7  易失性数字电位器, 10 kohm, 单, I2C, 线性, ± 20%, 2.7 V

The is an I²C-compatible Digital Potentiometer performs the same electronic adjustment function as a mechanical potentiometer or a variable resistor. This low temperature coefficient device is ideal for high accuracy and stability variable resistance adjustments. The wiper settings are controllable through the I²C-compatible digital interface, which can also be used to read back the present wiper register control word. The resistance between the wiper and either end point of the fixed resistor varies linearly with respect to the digital code transferred into the RDAC latch.

.

Full read/write of wiper register

.

power-ON preset to midscale

.

0.9µA at 3.3V Typical low power
