ADC1175CIMTC/NOPB

TEXAS INSTRUMENTS  ADC1175CIMTC/NOPB  模数转换器, 8 bit, 20 MSPS, 单, 4.75 V, 5.25 V, TSSOP

The is an Analog-to-digital Converter ADC that digitizes signals to 8-bit while consuming just 60mW of power typical. The low power ADC uses unique architecture that achieves 7.5-bit effective. Output formatting is straight binary coding. The excellent DC and AC characteristics of this device, together with its low power consumption and 5V single supply operation, make it ideally suited for applications. Furthermore, the ADC is resistant to latch-up and the outputs are short-circuit proof. The top and bottom of the ADC reference ladder is available for connections, enabling a wide range of input possibilities.

.

Internal sample-and-hold function

.

Internal reference bias resistors

.

Industry standard pin-outs

.

TRI-STATE Outputs

.

Green product and no Sb/Br
