ADC121S021CISDX/NOPB

模数转换器 - ADC Single Channel, 50 to 200 ksps, 12-Bit A/D Converter 6-WSON -40 to 85

DESCRIPON

The ADC121S021 is a low-power, single channel CMOS 12-bit analog-to-digital converter with a high-speed serial interface. Unlike the conventional practice of specifying performance at a single sample rate only, the ADC121S021 is fully specified over a sample rate range of 50 ksps to 200 ksps. The converter is based upon a successive-approximation register architecture with an internal track-and-hold circuit.

FEATURES

• Specified Over a Range of Sample Rates.

• 6-Lead WSON and SOT-23 Packages

• Variable Power Management

• Single Power Supply with 2.7V - 5.25V Range

• SPI™/QSPI™/MICROWIRE/DSP Compatible

APPLICATIONS

• Portable Systems

• Remote Data Acquisition

• Instrumentation and Control Systems
