ANALOG DEVICES AD5173BRMZ10 非易失性数字电位器, 10 kohm, 双, I2C, -20%, +55%, 2.7 V
数字电位计(双),Analog Devices
得捷:
IC DGTL POT 10KOHM 256TAP 10MSOP
立创商城:
AD5173BRMZ10
欧时:
数字电位计(双),Analog Devices### 数字电位计 - Analog Devices
贸泽:
Digital Potentiometer ICs IC Dual OTP 8Bit I2C
艾睿:
Ideal for radio frequency processing circuits this AD5173BRMZ10 digital potentiometer from Analog Devices belongs in your design. This digital potentiometer has a minimum operating temperature of -40 °C and a maximum of 125 °C. This device comes in tube packaging. This device uses a single power supply.
安富利:
Digital Potentiometer 256POS 10KOhm Dual 10-Pin MSOP
Chip1Stop:
Digital Potentiometer 256POS 10kOhm Dual 10-Pin MSOP Tube
Verical:
Digital Potentiometer 10kOhm 256POS Volatile 10-Pin MSOP Tube
罗切斯特:
AD5173 - 256-Position, One-Time Programmable, Dual-Channel, I2C Digital Potentiometer
DeviceMart:
IC POT DGTL DUAL 10K OTP 10MSOP
容差 ±20 %
供电电流 0.0035 mA
电路数 2
针脚数 256
时钟频率 400kHz max
电阻 10 kΩ
阻值偏差 ±20 %
静态电流 3.50 µA
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 2.7V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2.7 V
安装方式 Surface Mount
引脚数 10
封装 MSOP-10
长度 3 mm
宽度 3 mm
高度 0.85 mm
封装 MSOP-10
工作温度 -40℃ ~ 125℃
温度系数 ±35 ppm/℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
AD5173BRMZ10 ADI 亚德诺 | 当前型号 | 当前型号 |
AD5173BRMZ10-RL7 亚德诺 | 类似代替 | AD5173BRMZ10和AD5173BRMZ10-RL7的区别 |
AD5173BRM10-RL7 亚德诺 | 类似代替 | AD5173BRMZ10和AD5173BRM10-RL7的区别 |
AD5173BRM10 亚德诺 | 类似代替 | AD5173BRMZ10和AD5173BRM10的区别 |
