ADS7830IPWTG4

TEXAS INSTRUMENTS  ADS7830IPWTG4  模数转换器, 八路, 8 bit, 70 kSPS, 单, 2.7 V, 5.25 V, TSSOP

The is a 8-bit 8-channel Sampling Analogue-to-digital Converter with I²C interface. The ADS7830 is a single-supply, low-power, 8-bit single-supply low-power data acquisition device that features a serial I²C interface and an 8-channel multiplexer. The Analogue-to-digital A/D converter features a sample-and-hold amplifier and internal, asynchronous clock. The combination of an I²C serial, 2-wire interface and micropower consumption makes the ADS7830 ideal for applications requiring the A/D converter to be close to the input source in remote locations and for applications requiring isolation.

.

8-channel multiplexer

.

4 Differential/8 single-ended inputs

.

Standard, fast and high-speed modes I²C interface supports

.

180µW Standard mode

.

300µW Fast mode

.

675µW High-speed mode

.

Green product and no Sb/Br

ESD sensitive device, take proper precaution while handling the device.
