单/双/四通道数字电位器 1-/2-/4-Channel Digital Potentiometers
Use almost any kind of profile you want with the digital potentiometer from Analog Devices when adjusting resistance in your product. This digital potentiometer has a temperature range of -40 °C to 125 °C. This device comes in tube packaging. This device uses a single power supply.
得捷:
IC DGT POT 10KOHM 256TAP 14TSSOP
贸泽:
Digital Potentiometer ICs IC DUAL CH 8-BIT
艾睿:
Digital Potentiometer 256POS 10kOhm Dual 14-Pin TSSOP Tube
Jameco:
Digital Potentiometer 256 Position 10k Ohm Dual 14-Pin TSSOP
Chip1Stop:
Digital Potentiometer 256POS 10kOhm Dual 14-Pin TSSOP Tube
Verical:
Digital Potentiometer 256POS 10kOhm Dual 14-Pin TSSOP Tube
罗切斯特:
AD8402 - 2-Channel Digital Potentiometer
容差 ±20 %
供电电流 0.9 mA
电路数 2
针脚数 256
电阻 10 kΩ
阻值偏差 ±20 %
静态电流 10.0 nA
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 2.7V ~ 5.5V
安装方式 Surface Mount
引脚数 14
封装 TSSOP-14
高度 1 mm
封装 TSSOP-14
工作温度 -40℃ ~ 125℃
温度系数 ±500 ppm/℃
产品生命周期 End of Life
包装方式 Tube
RoHS标准 Non-Compliant
含铅标准 Contains Lead
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
AD8402ARU10 ADI 亚德诺 | 当前型号 | 当前型号 |
AD8402ARUZ10 亚德诺 | 完全替代 | AD8402ARU10和AD8402ARUZ10的区别 |
AD8402ARZ10 亚德诺 | 完全替代 | AD8402ARU10和AD8402ARZ10的区别 |
AD8402ARUZ100 亚德诺 | 类似代替 | AD8402ARU10和AD8402ARUZ100的区别 |
