AD5282BRU200-REEL7

单/双通道， 15 V / 5 V ， 256位I2C兼容数字电位计 Single/Dual,15 V/5 V,256-Position I2C-Compatible Digital Potentiometer

GENERAL DESCRIPTION

The AD5280/AD5282 provides a single-/dual-channel, 256-position digitally controlled variable resistor VR device.1 These devices perform the same electronic adjustment function as a potentiometer, trimmer, or variable resistor. Each VR offers a completely programmable value of resistance between the A terminal and the wiper or the B terminal and the wiper. The fixed A-to-B terminal resistance of 20 kΩ, 50 kΩ, or 200 kΩ has a 1% channel-to-channel matching tolerance. Nominal temperature coefficient of both parts is 30 ppm/°C. Another key feature of these parts is that they can operate up to +15 V or ±5 V.

FEATURES

  256 Position

  AD5280: 1-Channel

  AD5282: 2-Channel Independently Programmable

  Potentiometer Replacement

  20 kΩ, 50 kΩ, 200 kΩ

  Low Temperature Coefficient 30 ppm/°C

  Internal Power-On Midscale Preset

  5 V to 15 V Single-Supply; ±5.5 V Dual-Supply Operation

  I2C Compatible Interface

APPLICATIONS

  Multimedia, Video, and Audio

  Communications

  Mechanical Potentiometer Replacement

  Instrumentation: Gain, Offset Adjustment

  Programmable Voltage Source

  Programmable Current Source

  Line Impedance Matching
