AD5662WARMZ-1REEL7

16位属于nanoDAC采用SOT- 23 16-Bit nanoDAC in a SOT-23

Product Details

The AD5662, a member of the _nano_DAC® family of devices, is a low cost, low power, single 16-bit buffered voltage-out guaranteed monotonic DAC.

The part incorporates a power-on-reset circuit that depending on model ensures that the DAC output powers up to zero volts or midscale and remains there until a valid write takes place. Power consumption is typically 250 µA and the part contains a power-down feature that reduces the current consumption of the device to 1 µA at 5 V with software selectable output loads while in power-down mode.

The AD5662 utilizes a versatile three-wire serial interface that operates at clock rates up to 30 MHz and is compatible with standard SPI™, QSPI™, MICROWIRE™ and DSP interface standards. Its on-chip precision output amplifier allows rail-to rail output swing to be achieved.

**Product Highlights **

1. 16-Bit monotonic DAC; 12-Bit accuracy guaranteed.

2. Available in 8-lead SOT-23 and 8-lead MSOP package.

3. Power-on-reset to zero or midscale.

4. Low power. Operates with 2.7 V to 5.5 V supply. Typically consumes 0.35 mW at 3 V and 0.7 mW at 5 V, making it ideal for battery-powered applications.

5. Power-down capability. When powered down, the DAC typically consumes 50 nA at 3 V and 200 nA at 5 V

6. 10 µs settling time.

**

**

**Applications**

.

Process control

.

Data acquisition systems

.

Portable battery-powered instruments

.

Digital gain and offset adjustment

.

Programmable voltage and current sources

.

Programmable attenuators

### Features and Benefits

.

16-Bit monotonic DAC; 12-Bit accuracy guaranteed

.

Available in 8-lead SOT-23 and 8-lead MSOP package

.

Power-on-reset to zero or midscale.

.

10 µs settling time

.

Low power. Operates with 2.7 V to 5.5 V supply. Typically consumes 0.35 mW at 3 V and 0.7 mW at 5 V, making it ideal for battery-powered applications

.

Power-down capability. When powered down, the DAC typically consumes 50 nA at 3 V and 200 nA at 5 V
