AD7992BRMZ-1REEL

双通道， 12位ADC， I2C兼容 2-Channel, 12-Bit ADC with I2C-Compatible

Product Details

The AD7992 is a 12-bit, high speed, low power, successive- approximation ADC. The part operates from a single 2.7 V to 5.5 V power supply and features a conversion time of 2 µs. The part contains a two channel multiplexer and track/hold amplifier.

The AD7992 provides a two-wire serial interface which is compatible with I2C interfaces. The part comes in two versions, AD7992-0, and AD7992-1. Each version allows for a minimum of two different I2C addresses. The AD7992-0 supports Standard and Fast I2C interface Modes, while the AD7992-1 supports Standard, Fast, and two High-Speed I2C Interface Modes.

### Features and Benefits

.

12-Bit ADC with Fast Conversion Time: 2 µs

.

Two Single-Ended Analog Input Channels

.

Specified for VDD of 2.7 V to 5.5 V

.

Low Power Consumption

.

Fast Throughput Rate: - 188 kSPS

.

Sequencer Operation

.

Automatic Cycle Mode

.

I2C® Compatible Serial Interface

.

I2C® Interface supports:

Standard, Fast, and High-Speed Modes

.

Out of Range Indicator

.

Pin-Selectable Addressing via AS

.

Automatic Shutdown Mode: - 1 µA max
