2.5 V至5.5 V , 500微安, 2线接口四路电压输出, 8位/ 10位/ 12位DAC 2.5 V to 5.5 V, 500 uA, 2-Wire Interface Quad Voltage Output, 8-/10-/12-Bit DACs
GENERAL DESCRIPTION
The AD5305/AD5315/AD5325 are quad 8-, 10-, and 12-bit buffered voltage output DACs in a 10-lead MSOP that operate from a single 2.5 V to 5.5 V supply, consuming 500 µA at 3 V. Their on-chip output amplifiers allow rail-to-rail output swing with a slew rate of 0.7 V/µs. A 2-wire serial interface, which operates at clock rates up to 400 kHz, is used. This interface is SMBus compatible at VDD < 3.6 V. Multiple devices can be placed on the same bus.
得捷:
IC DAC 10BIT V-OUT 10MSOP
艾睿:
DAC 4-CH Resistor-String 10-bit 10-Pin MSOP Tube
安富利:
DAC 4-CH Resistor-String 10-bit 10-Pin MSOP
Chip1Stop:
DAC 4-CH Resistor-String 10-bit 10-Pin MSOP Tube
Verical:
DAC 4-CH Resistor-String 10-bit 10-Pin MSOP Tube
罗切斯特:
AD5315 - 2.5V to 5.5V, 500uA, 2-WIRE Interface Quad Voltage Output, 10-Bit DAC
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
AD5315BRM ADI 亚德诺 | 当前型号 | 当前型号 |
AD5315BRMZ 亚德诺 | 类似代替 | AD5315BRM和AD5315BRMZ的区别 |
AD5315BRMZ-REEL7 亚德诺 | 类似代替 | AD5315BRM和AD5315BRMZ-REEL7的区别 |
AD5315BRM-REEL7 亚德诺 | 类似代替 | AD5315BRM和AD5315BRM-REEL7的区别 |
