ANALOG DEVICES AD5667BCPZ-R2 数模转换器, 双路, 16 bit, 250 kSPS, 串行, 2.7V 至 5.5V, LFCSP, 10 引脚
GENERAL DESCRIPTION
The AD5627R/AD5647R/AD5667R, AD5627/AD5667 members of the nanoDAC family are low power, dual, 12-, 14-, 16-bit buffered voltage-out DACs with/without on-chip reference. All devices operate from a single 2.7 V to 5.5 V supply, are guaranteed monotonic by design, and have an I2C compatible serial interface.
FEATURES
Low power, smallest pin-compatible, dual nanoDACs
AD5627R/AD5647R/AD5667R
12-/14-/16-bit
On-chip 1.25 V/2.5 V, 5 ppm/°C reference
AD5627/AD5667
12-/16-bit
External reference only
3 mm x 3 mm LFCSP and 10-lead MSOP
2.7 V to 5.5 V power supply
Guaranteed monotonic by design
Power-on reset to zero scale
Per channel power-down
Hardware LDAC and CLR functions
I2C-compatible serial interface supports standard 100 kHz,
fast 400 kHz, and high speed 3.4 MHz modes
APPLICATIONS
Process control
Data acquisition systems
Portable battery-powered instruments
Digital gain and offset adjustment
Programmable voltage and current sources
Programmable attenuators
通道数 2
针脚数 10
位数 16
耗散功率 2.80 mW
采样率 250 ksps
分辨率Bits 16.0
工作温度Max 105 ℃
工作温度Min -40 ℃
数模转换数DAC 2
电源电压 2.7V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2.7 V
安装方式 Surface Mount
引脚数 10
封装 LFCSP-10
高度 0.73 mm
封装 LFCSP-10
工作温度 -40℃ ~ 105℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
军工级 No
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
AD5667BCPZ-R2 ADI 亚德诺 | 当前型号 | 当前型号 |
AD5667BRMZ-REEL7 亚德诺 | 完全替代 | AD5667BCPZ-R2和AD5667BRMZ-REEL7的区别 |
AD5667RBCPZ-R2 亚德诺 | 类似代替 | AD5667BCPZ-R2和AD5667RBCPZ-R2的区别 |
AD5667BCPZ-REEL7 亚德诺 | 类似代替 | AD5667BCPZ-R2和AD5667BCPZ-REEL7的区别 |
