AD7888ARUZ-REEL

2.7 V至5.25 V ，微功耗， 8通道， 125 kSPS时， 12位ADC，采用16引脚TSSOP 2.7 V to 5.25 V, Micropower, 8-Channel, 125 kSPS, 12-Bit ADC in 16-Lead TSSOP

Product Details

The AD7888 is a high speed, low power, 12-bit ADC that operates from a single 2.7 V to 5.25 V power supply. The AD7888 is capable of a 125 kSPS throughput rate. The input track-and-hold acquires a signal in 500 ns and features a single ended sampling scheme. The AD7888 contains eight single-ended analog inputs, AIN1 through AIN8. The analog input on each of these channels is from 0 to VREF. The part is capable of converting full power signals up to 3 MHz.

The AD7888 features an on-chip 2.5 V reference that can be used as the reference source for the A/D converter. The REF IN/REF OUT pin allows the user access to this reference. Alternatively, this pin can be overdriven to provide an external reference voltage for the AD7888. The voltage range for this external reference is from 1.2 V to VDD.

CMOS construction ensures low power dissipation of typically 2 mW for normal operation and 3 µW in power-down mode. The part is available in a 16-lead narrow body small outline SOIC and a 16-lead thin small shrink outline TSSOP package.

### Features and Benefits

.

Specified for VDD of 2.7 V to 5.25 V

.

Flexible Power/Throughput Rate Management

.

Shutdown Mode: 1 µA Max

.

Eight Single-Ended Inputs

|

.

Serial Interface:

SPI®/QSPI™/MICROWIRE™/DSP Compatible

.

16-Lead Narrow SOIC and TSSOP Packages

---|---
