AD7396ARZ

12 位，2 通道，Analog Devices### 数字到模拟转换器 - Analog Devices

12 位，2 通道，Analog Devices

得捷:
IC DAC 12BIT V-OUT 24SOIC

立创商城:
AD7396ARZ

欧时:
数模转换器 12 位，2 通道，Analog Devices### 数字到模拟转换器 - Analog Devices

艾睿:
DAC 2-CH R-2R 12-bit Automotive 24-Pin SOIC W Tube

Jameco:
Digital to Analog Converter 2 Channel Rail to Rail 12-Bit 24-Pin SOIC W

安富利:
The AD7396 series of dual, 12-bit and 10-bit voltageoutput digital-to-analog converters are designed to operate from a single +3 V supply. Built using a CBCMOS process, these monolithic DACs offer the user low cost and ease of use in single supply +3 V systems. Operation is guaranteed over the supply voltage range of +2.7 V to +5.5 V, making this device ideal for battery operated applications.A 12-bit wide data latch loads with a 45 ns write time allowing interface to fast processors without wait states. The double buffered input structure allows the user to load the input registers one at a time, then a single load strobe tied to both LDA+LDB inputs will simultaneously update both DAC outputs. LDA and LDB can also be independently activated to immediately update their respective DAC registers. An address input A/B decodes DACA or DACB when the chip select CS input is strobed. Additionally, an asynchronous RS input sets the output to zero-scale at power on or upon user demand. Power shutdown to submicroamp levels is directly controlled by the active low SHDN pin. While in the power shutdown state register data can still be changed even though the output buffer is in an open circuit state. Upon return to the normal operating state the latest data loaded in the DAC register will establish the output voltage.Both parts are offered in the same pinout, allowing users to select the amount of resolution appropriate for their applications without circuit card changes.The AD7396 are specified for operation over the extended industrial -40°C to +85°C temperature range. The AD7397AR is specified for the -40°C to +125°C automotive temperature range. AD7396 are available in plastic DIP, and 24-lead SOIC packages. The AD7397ARU is available for ultracompact applications in a thin 1.1 mm height TSSOP 24-lead package.

Chip1Stop:
DAC 2-CH R-2R 12-bit Automotive 24-Pin SOIC W Tube

Verical:
DAC 2-CH R-2R 12-bit Automotive 24-Pin SOIC W Tube

Newark:
# ANALOG DEVICES  AD7396ARZ  Digital to Analog Converter, Dual, 12 bit, Parallel, 2.7V to 5.5V, SOIC, 24 Pins

罗切斯特:
D/A Converter, Parallel, Word Input Loading, 70us Settling Time, PDSO24

DeviceMart:
IC DAC 12BIT PARALLEL 3V 24-SOIC
