ADS831EG4

TEXAS INSTRUMENTS  ADS831EG4  模数转换器, 8 bit, 80 MSPS, 单, 4.75 V, 5.25 V, SSOP

The is a pipeline CMOS Analog-to-digital Converter ADC that operates from a single 5V power supply. This converter provides excellent performance with a 1-ended input and can be operated with a differential input for added spurious performance. This high performance converter includes a 8-bit quantizer, high bandwidth track/hold and a high accuracy internal reference. It also allows for the user to disable the internal reference and utilize external references. This external reference option provides excellent gain and offset matching when used in multi-channel applications or in applications where DC full scale range adjustment is required. The ADC employs digital error correction techniques to provide excellent differential linearity for demanding imaging applications. It is specified at a maximum sampling frequency of 80MHz and a single-ended input range of 1.5 to 3.5V.

.

Internal or external reference

.

Single-ended or differential analog input

.

Programmable input range - 1Vp-p/2Vp-p

.

Green product and no Sb/Br
