AD5328BRU

2.5 V至5.5 V八通道电压输出8位/ 10位/ 12位DAC，采用16引脚TSSOP 2.5 V to 5.5 V Octal Voltage Output 8-/10-/12-Bit DACs in 16-Lead TSSOP

12 位 8 16-TSSOP

得捷:
IC DAC 12BIT V-OUT 16TSSOP

贸泽:
数模转换器- DAC 12 BIT SPI MICROPWR 6uS IC

艾睿:
DAC 8-CH Resistor-String 12-bit 16-Pin TSSOP Tube

安富利:
The AD5328 is octal 8-, 10-, and 12-bit buffered voltage output DACs in a 16-lead TSSOP. They operate from a single 2.5 V to 5.5 V supply, consuming 0.7 mA typical at 3 V. Their on-chip output amplifiers allow the outputs to swing rail-to-rail with a slew rate of 0.7 V/μs. The AD5328 use a versatile 3-wire serial interface that operates at clock rates up to 30 MHz and is compatible with standard SPI, QSPI, MICROWIRE, and DSP interface standards.The references for the eight DACs are derived from two reference pins one per DAC quad. These reference inputs can be configured as buffered, unbuffered, or VDD inputs. The parts incorporate a power-on reset circuit, which ensures that the DAC outputs power up to 0 V and remain there until a valid write to the device takes place. The outputs of all DACs may be updated simultaneously using the asynchronous LDAC input. The parts contain a power-down feature that reduces the current consumption of the devices to 400 nA at 5 V 120 nA at 3 V. The eight channels of the DAC may be powered down individually.

Chip1Stop:
DAC 8-CH Resistor-String 12-bit 16-Pin TSSOP Tube

Verical:
DAC 8-CH Resistor-String 12-bit 16-Pin TSSOP Tube

罗切斯特:
AD5328 - 2.5V to 5.5V Octal Voltage Output 12-Bit DAC

Win Source:
IC DAC 12BIT 2.5V OCTAL 16-TSSOP
