AD7899ARZ-1REEL

模数转换器 - ADC 5V SGL Supply 14-Bit 400 kSPS

Product Details

The AD7899 is a fast, low power, 14-bit A/D converter that operates from a single +5 V supply. The part contains a 2.0 µs successive approximation ADC, a track/hold amplifier, 2.5 V reference, on chip clock oscillator, signal conditioning circuitry and a high speed parallel interface. The part accepts analog input ranges of ±10 V , ±5 V, ±2.5 V, 0 V to +2.5 V and 0 V to +5 V. Overvoltage protection on the analog inputs for the part allows the input voltage to exceeded without damaging the parts or affecting a conversion in progress.

### Features and Benefits

.

Fast 2.2 µs 14-Bit ADC

.

400 kSPS Throughput Rate

.

0.3 µs Track/Hold Acquisition Time

.

Single Supply Operation

.

High-Speed Parallel Interface which Also Allows Interfacing to 3 V Processors

.

Low Power, 80 mW Typ

.

Selection of Input Ranges:

±10 V, ±5 V and ±2.5 V

0 V to 2.5 V and 0 V to 5 V

.

Power-Saving Mode, 20 µW Typ

.

Overvoltage Protection on Analog Inputs

.

Power-Down Mode via STBY Pin
