16位， 80 MSPS / 105 MSPS ADC 16-Bit, 80 MSPS/105 MSPS ADC
You"ll have no problem converting real world physical signals, such as light and temperature, into a sequence of digital data that a computer can read with this ADC from Analog Devices. It has a differential input signal. This device is based on Pipelined architecture. This device"s digital interface is parallel|lvds. This ADC has a resolution of 16bit. This ADC has an input voltage of 2 Vp-p/4Vp-p. This ADC has a temperature range of -40 °C to 85 °C.
电源电压DC 2.00V min
供电电流 290 mA
电路数 1
通道数 1
位数 16
耗散功率 1800 mW
采样率 80 Msps
分辨率Bits 16.0
输入电容 6.00 pF
输入阻抗 1.00 kΩ
模数转换数ADC 1
工作温度Max 85 ℃
工作温度Min -40 ℃
输入通道数 1
电源电压Max 3.46 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 100
封装 TQFP-100
高度 1 mm
封装 TQFP-100
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
军工级 No
REACH SVHC版本 2015/12/17
ECCN代码 3A001.a.5.a.5
