AD9713BBP

12位， 100 MSPS D / A转换器 12-Bit, 100 MSPS D/A Converters

GENERAL DESCRIPTION

The AD9712B and AD9713B D/A converters are replacements for the AD9712 and AD9713 units which offer improved ac and dc performance. Like their predecessors, they are 12-bit, high speed digital-to-analog converters fabricated in an advanced oxide isolated bipolar process. The AD9712B is an ECL compatible device featuring update rates of 100 MSPS mini mum; the TTL-compatible AD9713B will update at 80 MSPS minimum.

FEATURES

100 MSPS Update Rate

ECL/TTL Compatibility

SFDR @ 1 MHz: 70 dBc

Low Glitch Impulse: 28 pV-s

Fast Settling: 27 ns

Low Power: 725 mW

1/2 LSB DNL B Grade

40 MHz Multiplying Bandwidth

APPLICATIONS

ATE

Signal Reconstruction

Arbitrary Waveform Generators

Digital Synthesizers

Signal Generators
