AD9642BCPZRL7-250

14位， 170 MSPS / 210 MSPS / 250 MSPS ， 1.8 V模拟数字转换器（ ADC ） 14-Bit, 170 MSPS/210 MSPS/250 MSPS, 1.8 V Analog-to-Digital Converter ADC

GENERAL DESCRIPTION

The AD9642is a 14-bit analog-to-digital converter ADC with sampling speeds of up to 250 MSPS. The AD9642is designed to support communications applications, where low cost, small size, wide bandwidth, and versatility are desired.

FEATURES

SNR = 71.0 dBFS at 185 MHz AINand 250 MSPS

SFDR = 83 dBc at 185 MHz AINand 250 MSPS

−152.0 dBFS/Hz input noise at 200 MHz, −1 dBFS AIN, 250 MSPS

Total power consumption: 390 mW at 250 MSPS

1.8 V supply voltages

LVDS ANSI-644 levels outputs

Integer 1-to-8 input clock divider 625 MHz maximum input

Sample rates of up to 250 MSPS

Internal ADC voltage reference

Flexible analog input range

   1.4 V p-p to 2.0 V p-p 1.75 V p-p nominal

ADC clock duty cycle stabilizer

Serial port control

Energy saving power-down modes

APPLICATIONS

Communications

Diversity radio systems

Multimode digital receivers 3G

TD-SCDMA, WiMAX, WCDMA, CDMA2000, GSM, EDGE, LTE

I/Q demodulation systems

Smart antenna systems

General-purpose software radios

Ultrasound equipment

Broadband data applications
