12位逐次逼近INTERATED电路A / D转换器 12-BIT SUCCESSIVE APPROXIMATION INTERATED CIRCUIT A/D CONVERTER
PRODUCT DESCRIPTION
The AD ADC80 is a complete 12-bit successive-approximation analog-to-digital converter that includes an internal clock, reference, and comparator. Its hybrid IC design uses MSI digital and linear monolithic chips in conjunction with a 12-bit monolithic DAC to provide modular performance and versatility with IC size, price, and reliability.
FEATURES
True 12-Bit Operation: Max Nonlinearity 0.012%
Low Gain T.C.: 30 ppm/C Max
Low Power: 800 mW
Fast Conversion Time: 25 s
Precision 6.3 V Reference for External Application
Short-Cycle Capability
Parallel Data Output
Monolithic DAC with Scaling Resistors for Stability
Low Chip Count—High Reliability
Industry-Standard Pinout
Z Models for 12 V Supplies
数字逻辑电平 SAR
电源电压DC 5.00V min
供电电流 70.0 mA
电路数 1
通道数 2
位数 12
耗散功率 800 mW
采样率 40 ksps
功耗 800 mW
模数转换数ADC 1
输入数 2
工作温度Max 85 ℃
工作温度Min -25 ℃
输入通道数 2
安装方式 Through Hole
引脚数 32
封装 CDIP-32
长度 41.66 mm
宽度 22.99 mm
高度 4.32 mm
封装 CDIP-32
工作温度 -25℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
RoHS标准 Non-Compliant
含铅标准 Contains Lead
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ADADC80-12 ADI 亚德诺 | 当前型号 | 当前型号 |
ADADC80-10 亚德诺 | 完全替代 | ADADC80-12和ADADC80-10的区别 |
