双路，8位50 MSPS A / D转换器 Dual 8-Bit 50 MSPS A/D Converter
GENERAL DESCRIPTION
The AD9058 combines two independent, high performance, 8-bit analog-to-digital converters ADCs on a single monolithic IC. Combined with an optional on-board voltage reference, the AD9058 provides a cost-effective alternative for systems requiring two or more ADCs.
Dynamic performance SNR, ENOB is optimized to provide up to 50 MSPS conversion rates. The unique architecture results in low input capacitance while maintaining high performance and low power <0.5 W/channel. Digital inputs and outputs are TTL compatible.
FEATURES
2 Matched ADCs on Single Chip
50 MSPS Conversion Speed
On-Board Voltage Reference
Low Power <1 W
Low Input Capacitance 10 pF
65 V Power Supplies
Flexible Input Range
APPLICATIONS
Quadrature Demodulation for Communications
Digital Oscilloscopes
Electronic Warfare
Radar
