直流/直流开关调节器,Allegro Microsystems高电压降压转换器,具有效率竞争率。 可处理宽输入工作电压范围,此降压调节器通常用于消费性设备电源。### 开关电压调节器,Allegro Microsystems
直流/直流开关调节器,Allegro Microsystems
高电压降压转换器,具有效率竞争率。 可处理宽输入工作电压范围,此降压调节器通常用于消费性设备电源。
得捷:
IC REG BUCK ADJUSTABLE 2A 8SOIC
欧时:
Allegro Microsystems A4447SLJTR-T 降压 开关稳压器, 8 → 50 V输入, 2A最大输出, 0.8 → 24 V输出
立创商城:
降压型 Vin=8V~50V Vout=800mV~24V 2A
艾睿:
Adjust the voltage level of your devices with this step down A4447SLJTR-T DC to DC converter from Allegro MicroSystems. This converter&s;s single output can produce a current up to 2 A. The best way to provide power to your application is by using this, which needs a voltage of at least 8 V and no higher than 50 V. With an adjustable output that has a voltage of 0.8 to 24 V, this is power management at its best. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This converter has a minimum operating temperature of -20 °C and a maximum of 85 °C.
安富利:
Conv DC-DC Single Step Down 8V to 50V 8-Pin SOIC N EP T/R
Chip1Stop:
Conv DC-DC 8V to 50V Step Down Single-Out 0.8V to 24V 2A 8-Pin SOIC N EP T/R
Verical:
Conv DC-DC 8V to 50V Step Down Single-Out 0.8V to 24V 2A 8-Pin SOIC N EP T/R
DeviceMart:
IC REG BUCK ADJ 2A 8SOIC
Win Source:
IC REG BUCK ADJ 2A 8SOIC
输出接口数 1
输出电压 0.8V ~ 24V
输出电流 2 A
输入电压Max 50 V
输入电压Min 8 V
输出电压Max 24 V
输出电压Min 0.8 V
输出电流Max 2 A
工作温度Max 85 ℃
工作温度Min -20 ℃
电源电压 8 V
输入电压 50 V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
长度 4.9 mm
宽度 3.9 mm
高度 1.55 mm
封装 SOIC-8
工作温度 -20℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
A4447SLJTR-T Allegro MicroSystems 急速微电子 | 当前型号 | 当前型号 |
A8499SLJTR-T 急速微电子 | 类似代替 | A4447SLJTR-T和A8499SLJTR-T的区别 |
A8499SLJ-T 急速微电子 | 类似代替 | A4447SLJTR-T和A8499SLJ-T的区别 |
