LDO Regulator Pos 2.8V1.8V1.2V 0.2A 16Pin LFCSP EP T/R
Keep calm and stay stable by implementing this LDO linear regulator developed by Analog Devices. Its typical dropout voltage at current is 0.11@200mA V. It has an overall accuracy of ±1 %. This voltage regulation device"s 3 outputs can produce a current up to 0.2 A. This will operate at a minimum voltage of 1.8 V and a maximum voltage of 5.5 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 2.8|1.8|1.2 V, this is power management at its best. At a load regulation of 0.001%/mATyp and line regulation of 0.01%/VTyp a constant current can be produced at the output of your circuit. This product will be shipped in tape and reel packaging so that components can be mounted effectively. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C.
输出接口数 3
输出电压 1.2V ~ 3.3V
输出电流 200 mA
供电电流 250 µA
跌落电压 0.11V @200mA
输入电压Max 5.5 V
输入电压Min 1.8 V
输出电流Max 0.2 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±1 %
电源电压 1.8 V
输入电压 1.8V ~ 5.5V
安装方式 Surface Mount
引脚数 16
封装 LFCSP EP-16
长度 3 mm
宽度 3 mm
高度 0.73 mm
封装 LFCSP EP-16
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
军工级 No
