Power Supply; AC-DC; 12V; 16.7A; 90-264V In; Open Frame; PFC; Embedded; 200W; ABC Series
开放框架 AC DC 转换器 1 输出 12V - - - 13.33A 90 ~ 264 VAC 输入
得捷:
AC/DC CONVERTER 12V 160/200W
贸泽:
Switching Power Supplies 200W 12V 13.33A SCREW TERMINAL
艾睿:
AC/DC Power Supply Single-OUT 12V 13.33A 200W
Allied Electronics:
Power Supply; AC-DC; 12V; 16.7A; 90-264V In; Open Frame; PFC; Embedded; 200W; ABC Series
Chip1Stop:
AC/DC Power Supply Single-OUT 12V 13.33A 200W
Verical:
AC/DC Power Supply Single-OUT 12V 13.33A 200W
MASTER:
AC/DC Power Supply Single-OUT 12V 13.33A 200W
Online Components:
AC/DC Power Supply Single-OUT 12V 13.33A 200W
Electro Sonic:
AC/DC Power Supply Single-OUT 12V 13.33A 200W
Win Source:
AC/DC CONVERTER 12V 160/200W / Open Frame AC DC Converters 1 Output 12V 90 ~ 264 VAC Input
输出接口数 1
输出电压 12 V
输出电流 13.33 A
输出功率 200 W
隔离电压 4.242 kV
输入电压DC Max 390 V
输入电压DC Min 120 V
输入电压AC Max 264 V
输入电压AC Min 90 V
输出电流Max 13.33 A
输入电流Min 2.4 A
输出功率Max 200 W
工作温度Max 70 ℃
工作温度Min -20 ℃
输入电压 90VAC ~ 264VAC
长度 5 in
宽度 3 in
高度 38.1 mm
工作温度 -20℃ ~ 70℃
产品生命周期 Active
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8504409990
