ADP3335ARMZ-3.3-RL

高精度，超低智商500毫安，公司的anyCAP低压差稳压器 High Accuracy, Ultralow IQ, 500 mA, anyCAP Low Dropout Regulator

This LDO linear regulator from Analog Devices acts like a variable resistor to maintain a steady voltage level. Its typical dropout voltage at current is 0.2@500mA|0.14@300mA|0.03@50mA|0.01@100uA V. It has an overall accuracy of ±0.9 %. This voltage regulation device"s single output can produce a current up to 0.5 A. This will operate at a minimum voltage of 2.6 V and a maximum voltage of 12 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 3.3 V, this is power management at its best. At a load regulation of 0.04mV/mATyp and line regulation of 0.04mV/VTyp your circuit is capable of maintaining a constant voltage level at your output. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. Its polarity is positive. The maximum dropout voltage is 0.37@500mA|0.23@300mA|0.11@50mA|0.04@100uA V. This voltage regulation device has an operating temperature range of -40 °C to 85 °C.
