ANALOG DEVICES ADP5303ACBZ-1-R7 直流-直流开关降压稳压器, 可调, 2.15V-6.5V输入, 800mV-5V/500mA输出, 2 MHz, WLCSP-9
降压 开关稳压器 IC 正 可编程 0.8V 1 输出 50mA，500mA 9-WFBGA，WLCSP
得捷:
IC REG BUCK PROG 9WLCSP
立创商城:
降压型 Vin=2.15V~6.5V Vout=800mV~5V 500mA 50mA
贸泽:
Switching Voltage Regulators 50mA/500mA ULP Buck VINOK w/ OD
艾睿:
Conv DC-DC 2.15V to 6.5V Synchronous Step Down Single-Out 1.2V to 3.6V/0.8V to 5V 0.05A/0.5A 9-Pin WLCSP T/R
安富利:
Conv DC-DC Single Step Down 2.15V to 6.5V 9-Pin WLCSP T/R
Verical:
Conv DC-DC 2.15V to 6.5V Synchronous Step Down Single-Out 1.2V to 3.6V/0.8V to 5V 0.05A/0.5A 9-Pin WLCSP T/R
Newark:
# ANALOG DEVICES ADP5303ACBZ-1-R7 DC-DC Switching Buck Step Down Regulator, Adj., 2.15V-6.5Vin, 800mV-5V/500mA out, 2 MHz, WLCSP-9
输出接口数 1
输出电压 ≤5.00 V
输出电流 500 mA
针脚数 9
开关频率 2 MHz
输入电压Max 6.5 V
输入电压Min 2.15 V
输出电压Max 5 V
输出电压Min 800 mV
输出电流Max 0.5 A
工作温度Max 125 ℃
工作温度Min 40 ℃
输入电压 2.15V ~ 6.5V
安装方式 Surface Mount
引脚数 9
封装 WLCSP-9
封装 WLCSP-9
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Cut Tape CT
制造应用 Clinical Monitoring, Body Composition Measurement, Wearable Health Monitoring, Health, Wellness and Fitness, Sport Watch, Healthcare, Motion Sensing/Fall Detection, Medical Isolation and Patient Safety, Respiration Measurement, SpO2, EEG , Clinical, NiBP based on ECG and PPG, Portable Blood Analyzer
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
