ADP3335ARMZ-2.5-RL

高精度，超低智商500毫安，公司的anyCAP低压差稳压器 High Accuracy, Ultralow IQ, 500 mA, anyCAP Low Dropout Regulator

Product Details

The ADP3335 is a member of the ADP330x family of precision low dropout anyCAP voltage regulators. The ADP3335 operates with an input voltage range of +2.6 V to +12 V and delivers a continuous load current up to 500 mA. The ADP3335 stands out from the conventional LDOs with the lowest thermal resistance of any MSOP-8 package and an enhanced process that enables it to offer performance advantages beyond its competition. Its pat-ented design requires only a 1.0 µF output capacitor for stability. This device is insensitive to output capacitor Equivalent Series Resistance ESR, and is stable with any good quality capacitor, including ceramic MLCC types for space-restricted applications. The ADP3335 achieves exceptional accuracy of ±0.9% at room temperature and ±1.8% over temperature, line and load variations. The dropout voltage of the ADP3335 is only 200 mV typical at 500 mA. This device also includes a safety current limit, thermal overload protection and a shutdown feature. In shutdown mode, the ground current is reduced to less than 2 µA. The ADP3335 has ultralow quiescent current 60 µA typ in light load situations.

### Features and Benefits

.

High accuracy over line and load: ±0.9% @ 25°C, ±1.8% over temperature

.

Ultralow dropout voltage: 200 mV typ @ 500 mA

.

Requires only CO = 1.0 µF for stability

.

anyCAP = stable with any type of capacitor Including MLCC

.

Current and thermal limiting

.

Low noise

.

Low shutdown current: < 10 nA typ

.

2.6 V to 12 V supply range

.

–40°C to +85°C ambient temperature range
