ADP3335ARMZ-1.8-R7

ANALOG DEVICES  ADP3335ARMZ-1.8-R7  固定电压稳压器, LDO, 2.6V至12V, 200mV压差, 1.8V输出, 500mA输出, SOP-8

This LDO linear regulator developed by Analog Devices keeps the power stable! Its typical dropout voltage at current is 0.2@500mA|0.14@300mA|0.03@50mA|0.01@100uA V. It has an overall accuracy of ±0.9 %. This voltage regulation device"s single output can produce a current up to 0.5 A. It only needs a voltage of at least 2.6 V while not exceeding 12 V to effectively power your circuit. With a fixed output that has a voltage of 1.8 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 0.04mV/mATyp and line regulation of 0.04mV/VTyp. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. The maximum dropout voltage is 0.37@500mA|0.23@300mA|0.11@50mA|0.04@100uA V. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 85 °C.
